DBSG-09聲光報警器Z-05C
產品概述
DBSG-09聲光報警器是一款專為工業環境設計的高性能警報裝置，適用于港口、礦山、冶金等大型設備的安全預警。該產品采用一體化結構設計，集成了大功率揚聲器和高亮度LED警示燈，能夠在復雜環境中提供清晰可辨的聲光警示信號。產品支持多種工作電壓選擇，包括AC220V、AC380V、DC24V等，滿足不同場景的供電需求。外殼采用噴塑鋼板材質，具有優異的防塵防水性能，確保設備在惡劣環境下穩定運行。內置多種音調模式，包括工程音、消防音等固定音效，還可根據用戶需求定制語音提示內容，如"設備啟動請注意"等實用語音警報功能。123
核心特點
DBSG-09聲光報警器具備80W大功率輸出，聲音宏亮穿透力強，最大可達135分貝，確保在嘈雜工業環境中仍能被清晰識別。產品采用防風雨電路工藝設計，內部集成智能控制芯片，具有無噪音、壽命長、故障率低等優勢。警示燈采用高亮度LED光源，閃爍頻率可根據實際需求調節，視覺效果醒目。安裝方式簡便，支持壁掛式固定，配有標準接線端子，便于快速部署。特別適用于起重機械、門吊、橋吊等大型設備的安全警示，能有效預防工業事故的發生。產品工作溫度范圍寬(-30℃~+70℃)，適應各種氣候條件下的使用需求。713
應用場景
該聲光報警器廣泛應用于鋼鐵廠、焦化廠、礦山、冶煉廠等工業場所，以及港口碼頭、大型起重設備等作業區域。在工程車輛啟動、皮帶輸送機運行、天車移動等場景下，能及時發出聲光警示，提醒現場人員注意安全。產品也可用于銀行、商場、別墅等安防系統，作為周界防越的警示裝置。特殊設計的防水防塵結構使其適用于船舶機械等潮濕環境，鋁合金材質外殼具有良好的抗鹽霧腐蝕能力，延長了產品在沿海地區的使用壽命。319
Product Introduction
The DBSG-09 audio-visual alarm is a high-performance warning device designed for industrial environments, suitable for safety alerts in ports, mines, metallurgy and other large-scale equipment applications. This product features an integrated structure combining high-power speakers and bright LED warning lights, delivering clear and distinguishable audio-visual signals in complex working conditions. It supports multiple operating voltages including AC220V, AC380V and DC24V to meet different power supply requirements. The enclosure is made of spray-coated steel plate with excellent dustproof and waterproof performance, ensuring stable operation in harsh environments. Built-in multiple tone modes include engineering sound, fire alarm sound and other fixed sound effects, with customizable voice prompts like "Equipment starting, please pay attention" available upon request.17
Key Features
The DBSG-09 alarm delivers powerful 80W output with clear penetrating sound up to 135dB, ensuring audible recognition in noisy industrial environments. Its weatherproof circuit design incorporates intelligent control chips, offering noiseless operation, long service life and low failure rate. The warning light uses high-brightness LED sources with adjustable flashing frequency for eye-catching visual effects. Simple wall-mount installation with standard wiring terminals enables quick deployment. Particularly suitable for safety warnings on cranes, gantry cranes and bridge cranes, effectively preventing industrial accidents. With wide operating temperature range (-30℃~+70℃), it adapts to various climatic conditions.1323
Application Scenarios
This alarm is widely used in steel plants, coking plants, mines, smelters and other industrial sites, as well as port terminals and large lifting equipment areas. It provides timely audio-visual warnings during engineering vehicle startup, conveyor belt operation and overhead crane movement to remind personnel of potential hazards. The product also serves security systems in banks, shopping malls and villas as perimeter protection warning devices. Specially designed waterproof and dustproof structure makes it suitable for marine machinery in humid environments, while aluminum alloy housing provides excellent salt spray corrosion resistance for extended service life in coastal regions.319
DBSG-09聲光報警器Z-05C
|
接線方法
|
|
|
|
電源線 引入口(CABLE ENTRY)
|
|
|
|
|
|
1.使用防水接頭或者船舶用填料函
|
|
|
2.電源線 接入口:標準規格 : PF 1/2
|
|
|
3.引入口 PF 3/4 尺寸可以定做
|
|
|
接線方法
|
|
|
1.AC交流電源產品：不用分正負極,直接連接電源.
|
|
|
2.DC直流電源產品：黑色線端子連接在負極(-)。
|
|
|
3.為了更**的連接,電源線的端部使用冷壓接線端子“O"型"U"型
|
|
|
|
